HGL
Swinging top beam working on high precision and self-aligning roller bearings.
HGL is an economical and user-friendly hydraulic shearing machine designed for light sheet metal cutting tasks. Featuring a swing-beam upper blade movement, HGL delivers clean, straight cuts with reliable performance and low operating costs—making it the ideal choice for small-to-medium workshops, maintenance units, and entry-level fabrication businesses.
Sturd Body & Hydraulic Unit
Welded all-steel frame providing maximum rigidity and cutting accuracy. Compact, low-maintenance hydraulic unit located underneath work table.
Swing-Beam Concept
Swinging top beam working on high precision and self-aligning roller bearings.
Control Unit
Cybtouch 8 is standard.
ESA 625 is optional.
Front Finger Guard
Fixed is standard. 1m-Lift-Up (with safety switch) and Light Barrier are optional.
Rear Light Barrier
Standard.
Backgauge
Standard 750mm backgauge with ballscrew spindles to 0.1 mm precision.
1000mm is optional.
Blade
Shear blades from tough and wear-resistant alloyed material. Top blade has 2 cutting edges while bottom one has four. Hardened blades for stainless steel cutting is optional.
Blade Gap Adjustment
Rapid blade gap adjustment mechanism
Manual is standard, Motorized is optional
Front Support Arms
1000mm is standard
T-slot and flip-stop types and 1500, 2000, 3000mm are optional.
Holddown pads
Standard
Shadow Line
Shadow line facility with fluorescent lighting
Standard.
Laser Line
It enables to see clearly the cutting point.
Optional
Pneumatic Sheet Supports
Pneumatic rear support systems for thin sheets. It’s optional
A-Type (for <13mm), U-Type (for <13mm).
Optional.
Angle Gauge
Optional
Squaring Arm
1000mm is standard.
1500,2000,3000,4000mm are optional
Drawer
It enables to take small cut parts from the front.
Optional
RTS Function
It brings cut parts to the front.
Standard for U type pneumatic sheet support system
Lubrication
Centralised manual lubrication system.
Standard
Foot Pedal
Standard
Work Table
Work table with filler plates, ball transfers and hand slots
Standard
Emergency Stop
Standard
Cost-Effective Shearing Solution
A great entry-level option with low initial investment and minimal maintenance needs.
Reliable Design
The fastest cutting model in the shear cutting group with a unique engineering design
Simple to Operate
Designed for ease of use—ideal for operators with limited training or experience.
Compact and Workshop-Friendly
Fits easily into smaller production spaces while still handling standard sheet sizes.
